• 인터페이스: 2 x USB2.0,4 x USB2.0,3 x USB2.0,TF 카드 지원,USB OTG,HDMI 호환/RCA 출력
• 프로세서 브랜드: 록칩(Rockchip)
• 통합 기능: 10/100 Mbps,와이파이/g/n을,IR 수신기,bluetooth
• 모델 번호: Fi-S905
• 데모 보드 유형: 팔
• 브랜드 이름: liontron
• 근원: CN (정품)
• DDR/RAM: LPDDR4 1GB (2GB|4GB optional)
• Storage/ROM: 8GB/16GB/32gb/63GB/128GB EMMC NAND
• HDMI Output: 4K
• MIPI-DSI: 1920x1200
• COM/Serial Port: 1 TTL/RS-232/RS-485 compatible 1 TTL/RS-232 compatible 1 TTL port
• GPIO Signals: 5-way GPIO
• I2C Bus: I2C pin header and FPC for I2C capacitive screen and etc
• DC Input: 9~15V wide voltage
• Ambient Requirement: Working temperature -20°C ~ 70°C, working humidity 0%~95% (non-condensing)
• Physical Size: 110mm*68mm*10mm PCB top side height 5.5mm
• Operating System: Recommended Android 9.0
• Wiegand port: 1 Wiegand input and 1 Wiegand output port
• Door Control: Single-pole double-throw access control relay interface (Maximum 2A)
• Baclight Control: Industry standard LCD backlight control header AND support for backlight switch and brightness adjustment
• System Expansion: With 12V power supply/5V output/ 2 independent USB Host/ 1 muxed USB OTG/ u-boot burn key/ power switch key/ reset key and 2 GPIOs
• Security Port: 1 Tamper-proof port
• USB 2.0 Interface: 4 USB 2.0 4P pin headers 1 USB 2.0 OTG 4P pin header or extended pin header
