SEAFLO55 Series Automatic Demand Diaphragm Pump 12V 20.0LPM 60PSI

The
55 Series is our Heavy-Duty water pump. It provides high volume water
flow with reduced pump cycling, thanks to the large five-chamber
diaphragm. These models are designed to run on water systems with no
accumulator tank necessary, and up to five fixtures! It is also suited
for use with a holding tank water system, as may be found in a boat, RV
or remote cabin. It provides up to 5.0 gallons per minute. The 55-Series
pumps are self-priming, and can run dry without damage, performance
reliable and low current. This automatic demand water system pump has a
built-in pressure switch, which automatically starts and stops the pump
when the faucet is opened and closed.They are easy to install service
and winterize.

MORE FEATURES & BENEFITS


-Can supply up to 4 fixtures
-Precise pressure control and stable performance
-Good sealing performance,waterproof and dustproof
-Low starting pressure,reduces cycling
-Good heat dissipation

-Run dry safe
-Can be use for Fresh&Salt Water
-2 Year Warranty
-Meets or exceeds RoHS, SGS, and ISO standards

TYPICAL APPLICATIONS

Marine,RV,Agricutural Spraying,General Industial,Filtration,Beverage Processing,Solar Water System.

PUMP

Type

5 Chamber positive displacement diaphragm pump, self priming, capable of being run dry

Control Type

Pressure switch

Max Recommended Temperature

60° C（140° F）

Priming Capabilities

6 feet (1.8 m) suction lift

Re-start Pressure

Shut-on Pressure 20 PSI ：20 PSI ±3 PSI

Shut-off Pressure 60 PSI ：60 PSI ±3 PSI

Inlet/Outlet Ports

1/2"-14 MNPT

Weight

6.1 lbs (2.8 kg)


MOTOR

Leads

14 AWG, 13" (33 cm) long with 2-Pin connector / Leads

Duty Cycle

Continuous

Max.Amp Draw

17.0 A

Fuse

25.5 A


HEAT RISE

DIMENSIONS
